Specialized Roval Torque Cap Front Hub End Caps 31mm OEM
Specialized Roval Torque Cap Front Hub End Caps 31mm OEM
Stage 21 Bikes
23582 Moulton Parkway
#111
Laguna Woods CA 92637
United States
Choose options
Specialized Roval Torque Cap Front Hub End Cap Set
Factory OEM | 31mm OD | Roval Low-Flange MTB Hubs | S205900007
The Specialized Factory Replacement Roval Torque Cap Front Hub End Cap Set is a genuine OEM solution for compatible Roval Low-Flange Mountain (LFM) front hubs used with RockShox Torque Cap-compatible forks.
These oversized 31mm OD Torque Caps provide the proper interface between a compatible Roval front hub and RockShox Torque Cap fork. The larger hub-to-fork contact area is designed to support the Torque Cap system's intended front-end interface while maintaining the original factory hub configuration.
The complete set includes both the drive-side and non-drive-side end caps.
Available from Stage 21 Bikes, your trusted source for hard-to-find Specialized OEM replacement parts.
Key Features
- Genuine Specialized / Roval factory OEM replacement parts
- Designed for compatible Roval Low-Flange Mountain (LFM) front hubs
- RockShox Torque Cap-compatible configuration
- Oversized 31mm outside diameter
- Thru-axle front hub application
- Includes drive-side and non-drive-side end caps
- Suitable for replacement or conversion of compatible Roval hubs
- Factory-correct fit for specified Roval performance wheel systems
Specifications
| Specification | Details |
|---|---|
| Brand | Specialized / Roval |
| Component | Front Hub Torque Cap End Cap Set |
| Hub Application | Roval Low-Flange Mountain (LFM) |
| Axle Type | Thru-Axle |
| Torque Cap OD | 31mm |
| Drive-Side End Cap | 1 Included |
| Non-Drive-Side End Cap | 1 Included |
| Quantity | 2 End Caps Total |
| MPN | S205900007 |
Kit Includes
- 1 × Drive-Side Torque Cap End Cap
- 1 × Non-Drive-Side Torque Cap End Cap
Specialized installation tool S215300002 is not included.
Installation Note
Installation of these hub end caps requires the appropriate end cap drift tool:
Specialized End Cap Drift Tool – S215300002
Using the correct installation tool helps ensure the end caps are properly seated without damaging the hub or replacement components.
OEM Compatibility
2027
- Roval Control World Cup
2026
- S-Works Epic World Cup – SRAM XX SL AXS / RockShox Ultimate Flight Attendant
- S-Works Epic 8 – SRAM XX SL AXS / RockShox Ultimate Flight Attendant
2025
- S-Works Epic World Cup LTD – Forward 50 Collection
- S-Works Epic World Cup – SRAM XX SL AXS / RockShox Ultimate
- Roval Control SL Team
- Roval Control SL 29 CL MS Wheelset
- Roval Control SL 29 6B XD Wheelset
2024
- S-Works Epic World Cup – SRAM XX SL AXS / RockShox Ultimate
- S-Works Epic World Cup
- S-Works Epic 8 – SRAM XX SL AXS / RockShox Ultimate Flight Attendant
2023
- S-Works Epic World Cup – SRAM XX AXS / RockShox Ultimate
- S-Works Epic World Cup
- S-Works Epic LTD
- S-Works Epic EVO – SRAM XX1 AXS / RockShox Ultimate
- S-Works Epic EVO
- S-Works Epic – SRAM XX1 AXS / RockShox Ultimate BRAIN
- S-Works Epic
2022
- S-Works Epic Hardtail
- S-Works Epic EVO
- S-Works Epic – Speed of Light Collection
- S-Works Epic
2021
- S-Works Epic Hardtail
- S-Works Epic EVO – SRAM XX1 AXS / RockShox Ultimate
- S-Works Epic
- Roval Control SL 29 Center Lock Front
- Roval Control SL 29 6-Bolt Front
- Epic S-Works – Speed of Light
Compatibility Notes
- Designed for compatible Roval Low-Flange Mountain front hubs.
- Intended for use with compatible RockShox Torque Cap fork interfaces.
- Torque Cap outside diameter is 31mm.
- Includes both front hub end caps.
- These are front hub components and are not intended for rear hubs.
- Hub configurations can vary even between wheels with similar names. Verify the hub model and Specialized MPN S205900007 before ordering.
- Installation requires Specialized End Cap Drift Tool S215300002, sold separately.
Why Use Roval Torque Caps?
RockShox Torque Cap-compatible forks use an oversized hub end-cap interface to increase the contact area between the front hub and fork dropouts. For compatible Roval wheel systems, the correct Torque Cap end caps maintain this intended interface while preserving proper hub alignment and factory fitment.
Genuine Specialized / Roval S205900007 provides the correct 31mm OD Torque Cap configuration for compatible Roval LFM front hubs, making it an ideal OEM solution when replacing damaged or missing end caps or converting a compatible hub to a Torque Cap setup.
Stage 21 Bikes carries genuine Specialized and Roval factory replacement parts to keep hard-to-find wheel and hub components in service.
