Shimano 105 FC-RS520 Crankset - 172.5mm 12-Speed 50/34t 110 Asymmetric BCD Hollowtech II Spindle Interface BLK

Shimano 105 FC-RS520 Crankset - 172.5mm 12-Speed 50/34t 110 Asymmetric BCD Hollowtech II Spindle Interface BLK

$135.00
SKU: EFCRS520DX04
Quantity:
In stock
Pickup available at Stage 21 Bikes Usually ready in 24 hours

Shimano 105 FC-RS520 Crankset - 172.5mm 12-Speed 50/34t 110 Asymmetric BCD Hollowtech II Spindle Interface BLK

Stage 21 Bikes

Pickup available, usually ready in 24 hours

23582 Moulton Parkway
#111
Laguna Woods CA 92637
United States

+19497163363
The Shimano 105 FC-RS520 is a 2-piece 4-arm crank that's compatible with modern disc brake road frames.
  • 4-arm crankset for 12-speed drivetrain
  • Compatible with frames of O.L.D. 135mm and 410mm chainstay length
  • 44.5mm chainline
  • 150mm Q-factor
  • Compatible with HG 12-speed chains
    Color Black
    Rings 50/34
    Number of Chainrings Double
    Crank Length (mm) 172.5
    Crank Intended Use Road
    Drivetrain Speeds 12
    BB Included No
    Pedal Spindle 9/16"
    Spindle Interface Type Shimano Hollowtech II
    Chainring BCD 110 Shimano Asymmetric
    Chainline/Hub Compatibility 135/142 Road Disc Hubs > 415 mm Chainstay
    Defined Color Black
    keyword search 105
    Crank Length 172.5Mm
